MR Series _ High Voltage Multi-Range DC Power Supplies
MR Series
MR Series High-Voltage Multi-Range DC Power Supplies deliver up to 5 kW of clean, low-noise output in a compact 2U form factor. Designed for both benchtop use and automated test systems, they offer wide voltage and current ranges with fast response and excellent regulation. The intuitive front panel enables easy list programming and slew rate control, while built-in software supports test sequencing and data logging without coding. Multiple interfaces—including USB, GPIB, LAN (LXI), and analog enable flexible remote control and system integration.
Key Features
Wide Output Flexibility – Delivers up to 1000 V or 120 A with multi-range operation, replacing multiple fixed-range power supplies and reducing system complexity.
High Power Density – Up to 5 kW in a compact 2U form factor, ideal for space-constrained test benches and ATE systems.
Advanced Control & Connectivity – Supports USB, RS232, GPIB, and LXI-compliant LAN, plus galvanically isolated analog control for seamless integration.
Precision & Protection – Features fast regulation, adjustable voltage/current slew rates, remote sense, and comprehensive protections (OVP, OCP, OPP, OTP).
Built-In Test & Simulation Tools – Includes list mode, LED mode, and an integrated Solar Array Simulator (SAS) with I-V curve generation and MPPT monitoring.
Scalable System Architecture – Master/Slave operation enables parallel connection up to 50 kW and control of up to 50 units from a single PC.
