SQ1500-3F RANGE_Din-Rail Application_ AC-DC
SQ976-3F-400-500
The SQ1500-3F RANGE is a high-efficiency, 1500 W DIN rail power supply designed for demanding industrial applications. Offering single trimmable DC outputs of +12 V, +24 V, or +48 V, it supports wide AC input ranges from 80 to 576 Vac (single/three phase) and DC inputs up to 810 Vdc. Fully enclosed and fan-cooled, it integrates EMC filtering, inrush current limiting, fusing, and robust protection against over-current, over-voltage, and short circuits. With CE marking and compliance to industrial safety and EMC standards, the SQ1500-3F ensures reliable operation in electrical cabinets via EN 50022 DIN rail mounting. Ideal for industrial controls, PLCs, battery charging, and instrumentation, it delivers performance, safety, and long-term dependability.
Features
High Power Output: 1500 W DIN rail power supply for demanding industrial loads
Flexible Inputs: Wide AC range (80–576 Vac, single/three-phase) and DC input up to 810 Vdc
Selectable Outputs: Trimmable +12 V, +24 V, or +48 V variants
Built-in Protections: Over-current, over-voltage, short-circuit, and inrush limiting
Industrial Compliance: CE-marked, safety & EMC certified for reliable cabinet integration
Rugged Design: Fully enclosed, fan-cooled housing with TS35 DIN rail mounting
