SQ1200-1F_RANGE
The SQ1200‑1F RANGE is a robust 1200 W DIN‑rail, single‑output power supply delivering selectable 24 V, 48 V, or 96 V outputs with precision trimmer for fine voltage adjustment. Operating from 94‑264 VAC or optional 90‑150 VDC inputs, it maintains high efficiency (~89 %) and a strong power factor (~0.96). Equipped with essential protections including short‑circuit auto‑restart, over‑current, over‑voltage safeguards, inrush limiting, and LED status indicator—it ensures steady, safe operation. Designed to industrial-grade standards (EN 62368‑1 safety, IEC 61000‑3‑2, 6‑2, 6‑3 EMC) and offers forced-air cooling with hold-up capability for resilient performance. Ideal for integration in automation, industrial controls, PLC systems, and instrumentation where long-term stability and compliance are crucial.
Features
- 1200 W Output Power — robust capacity for heavy-duty industrial applications.
- Select‑able Output Voltages — finely adjustable 24 V, 48 V, or 96 V output via trimmer.
- Wide Input Range — supports 94‑264 VAC or optional 90‑150 VDC for versatile deployment.
- Comprehensive Protections — auto‑restart short‑circuit, overcurrent/overvoltage safeguards, and LED status indicator.
- Industrial‑Grade Compliance — meets EN 62368‑1, EMC EN 61000‑3‑2/6‑2/6‑3 standards, with forced-air cooling.
- Reliable & Precise — ~89 % efficiency, ~0.96 power factor, temperature compensated, holds output during brief input dips.
